Best Seller FTTH Steel Tube Type Fiber Optic PLC Splitter 1.0m Without Connectors 09mm Myrayftth Patent 1X8
NINGBO MYRAY NETWORK EQUIPMENT CO.,LTD. was founded in 2006. The company is located in the east of Guanhaiwei Town Indus
Send your inquiryDESCRIPTION
Basic Info
| Model NO. | MRMPLCSWO108100044 |
| Application | Fiber Distribution Frame, Network Equipment, Fiber Module |
| Light Source TYPE | Laser |
| Connector Type | W/O Connector |
| Brand | Myrayftth |
| Package Size | 60mm X 7mm X 4mm |
| Fiber Diameter | 0.9mm |
| Package Type | Steel Tube Type |
| Input End | 1 Way |
| Output End | 8 Way |
| Splitter Type | Mini Type / Steel Tube Type |
| Fiber Type | G657A1 |
| Fiber Colour | White / Coloured |
| Wide Operating Wavelength | 1260 - 1650 Nm |
| Used in | FTTH / FTTX |
| Warranty | 2 Years |
| Temperature | -35ºC - +85ºC |
| From | Ningbo, China |
| Product Capacity | 360000piese/Year |
| Fiber Length | 1.0m |
| Transport Package | Blister Package Plus Carton |
| Specification | 1X8, Bare Type |
| Trademark | MYRAYFTTH |
| Origin | China |
| HS Code | 85367000 |
| Production Capacity | 360000pieces/Year |
Product Description
NINGBO MYRAY NETWORK EQUIPMENT CO.,LTD. was founded in 2006. The company is located in the east of Guanhaiwei Town Industrial Park of Cixi City, which is the hometown of hardware in China. It is close to 329 National Road and G15 Shenhai Expressway. The transportation is convenient and fast.
The company has passed the ISO 9001; 2008 international quality system certification, with first-class production equipment and testing equipment, and complete testing methods, good quality service so that our products won the trust of our customers.
The company is mainly engaged in the production and sale of optical fiber connector fittings and various optical fiber adapters and their peripheral supporting products. It can also carry out the development and manufacture of various plastic molds according to customer requirements, and adjust the appropriate materials and color matching.
The company specializes in the development of new connector fittings with hundreds of products, and has obtained LC and other connector patents. It has a professional research and development, mold production team, and equipped with a complete mold manufacturing workshop and SKD mirror spark machine, wire cutting, precision grinder, high-speed milling, high-speed perforation and other molds plus. The factory implements the complete processing of the mould.
The company has a self-built production plant with 20000, the main production equipment has 600 hardware lathes, 50 Haitian injection molding machine.
| Mechanical Specification 1xN | |||||||||||
| Mini Type PLC Splitter | |||||||||||
| Type | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | |||||
| Mini Type (Steel Tube) | Body Material | SUS304 | |||||||||
| Dimension(LxWxH/mm) | 60 x 7 x 4 | 60 x 12 x 5 | 80 x 20 x 6 | 100 x 40 x 6 | |||||||
| Input fiber type | 900um loose Hytrel/LSZH tube | ||||||||||
| Output fiber type | 901um loose Hytrel/LSZH tube | ||||||||||
| Input Length | 0.5M~1.5M(+50mm / -0mm)or Customized | ||||||||||
| Output Length | 0.5M~1.5M(+50mm / -0mm)or Customized | ||||||||||
| Connector (Input) | W/O Connector, SC/UPC,SC/APC,LC/UPC,LC/APC,FC/UPC,FC/APC | ||||||||||
| Connector (Output) | W/O Connector, SC/UPC,SC/APC,LC/UPC,LC/APC,FC/UPC,FC/APC | ||||||||||
| Optical Specification 1xN | |||||||||||
| 1 x N PLC Splitter | |||||||||||
| Type | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | |||||
| Fiber Type | G.657A | ||||||||||
| Operating Wavelength(mm) | 1260 to 1650 nm | ||||||||||
| Insertion Loss(dB) | Max(with connector) | 4 | 7.2 | 10.5 | 13.8 | 16.8 | 20.5 | ||||
| Uniformity Loss(dB) | Max | 0.6 | 0.6 | 0.8 | 1.2 | 1.5 | 1.8 | ||||
| Polariation Dependent Loss(dB) | Max | 0.2 | 0.2 | 0.2 | 0.3 | 0.3 | 0.5 | ||||
| Return Loss(dB) | UPC≥50 APC≥60 | ||||||||||
| Operating Temperature(ºC) | :-40ºC - +85ºC | ||||||||||
