1310&1550nm Polarization Maintaining Variable Optical Attenuator
1310&1550nm Polarization Maintaining Variable Optical Attenuator Product Description PM VOA is an useful tool for the op
Send your inquiryDESCRIPTION
Basic Info
Model NO. | LW-PMVOA |
Sleeve Material | Ceramic |
Connector Gender | Sc Male to Female |
Attenuation Accura | ±10% |
Return Loss | ≥50dB |
Color | Silver |
Keywords | Variable Inline Optical Attenuator |
Product Name | Polarization Maintaining Variable Optical Attenuat |
Transport Package | Carton |
Specification | Male to Female |
Trademark | LIGHTWIT |
Origin | China |
HS Code | 8517699000 |
Production Capacity | 5000PCS/Month |
Product Description
1310&1550nm Polarization Maintaining Variable Optical AttenuatorProduct Description
PM VOA is an useful tool for the optical components and systems test. The PM Manual Variable Optical Attenuator (1310&1550nm) is designed and manufactured to reduce the output optical power, get the power suitable. It is with low insertion loss, high extinction ration, high return loss and low Adjustment Precision, The PM Attenuator is widely applied at fiber laser ,fiber CWDM/DWDM/OADM communication system.
Features:
High precise attenuation value from 1~30dB
Low insertion loss and high return loss
Perfect environmental stability and reliability
High-power light source durability
Easy installation
Comply with IEC standards
RoHS compliant
Application:
Fiber optical telecommunication system
Optical transmission system
FTTH, CATV, WAN, fiber optical sensor
Metropolitan area network.
Product Specification
Parameter | value | ||
Grade | - | P | A |
Center Wavelength | nm | 1310 ,1480, 1550 | |
Operating Wavelength Range | nm | ±40 | |
Max. Original loss | dB | 0.5 | 0.6 |
Attenuation range | dB | 0.5 ~ 60 | 0.6 ~ 60 |
Min. Return loss | dB | 50 | |
Adjustment Precision | dB | 0.02 | |
Min. Extinction ratio | dB | 20 | |
Max. Power Handling | mW | 500 | |
Max. Tensile Load | N | 5 | |
Fiber type | - | PM Panda fiber | |
Operating temperature | ºC | 0 ~ +70 | |
Operating temperature | ºC | -40 ~ +85 | |
Dimensions | mm | 26×18×8 |
1. Above specifications are for device without connector.
2. For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower and ER will be 2dB lower. The default connector key is aligned to slow axis. Power transmit through the connector less than 2W.
Order Information
1 | 2 | 3 | 4 | 5 | 6 |
wavelength | Grade | Fiber Type | Pigtails Diameter | Fiber Length | Connector |
98:980nm30:1030nm64:1064nm13:1310nm15:1550nmXX: Others | P:P GradeA:A Grade | 1: Panda fiberX:Others | 90:900μm20:2.0mm30:3.0mmXX: Others | 08:0.8m10:1.0mXX: Others | 00:NoneFP: FC/PCFA: FC/APCSP: SC/PCSA: SC/APCLP: LC/PCLA: LC/APCXX: Others |
